| Image | Description | Action |
|---|---|---|
|
PS 12 SeriesA modular UPS system with hot-swappable power modules (4kVA to 12kVA) and customizable 4-slot design. Features adjustable battery capacity, DSP technology for reliability, high input power factor , and supports 50/60Hz frequency conversion. Offers energy-saving ECO mode, emergency power off, generator compatibility, and high efficiency (up to 99.0%). Equipped with LCD displays for easy monitoring. |
|
|
PS 15 SeriesAdvanced DSP-based True Online UPS with 3-Level IGBT technology. Features wide input voltage/frequency range, low harmonics, high power factor, and flexible 1-Phase & 3-Phase input configurations. Includes hot-swappable modules, emergency shutdown, generator compatibility, and cold start function. Intelligent fan control and active PFC for energy efficiency and extended system life. |
|
|
PS 32 SeriesThe PS32 series modular, online UPS ranging from 16kVA to 320kVA is designed to protect any critical load for medium and large data center achieving maximum availability. The PS32 series feature the latest technology of 3-level technology, PFC input control & Input Phase Sequence Correction, which guarantees ultra high efficiency of 96.8% and reliability. |
|
|
PS 50 SeriesThe PS50 Series is a modular, true online double conversion UPS (50kVA–1000kVA) designed for critical loads in medium to large data centers. It features advanced 3-level IGBT and PFC input control with phase sequence correction, delivering up to 97.1% efficiency. With compact design, up to 1000kVA fits in one cabinet, and scalability up to 6000kVA with parallel units ensures high availability and flexibility. |
|
|
PS 75 SeriesThe PS75 series modular, true online double conversion transformer-less design with 3-Level IGBT Inverter topology UPS ranging from 75kVA to 1200kVA is designed to protect any critical load for medium and large data center achieving maximum availability. The PS75 series feature the latest technology of DSP Microprocessor based control, using IGBT devices, high switching frequency PWM and PFC input control & Input Phase Sequence Correction, which guarantees ultra high efficiency of 97.1% and reliability. |
|
|
PS 100 SeriesThe PS100 series modular, true online double conversion transformer-less design with 3-Level IGBT Inverter topology UPS ranging from 100kVA to 1200kVA is designed to protect any critical load for medium and large data center achieving maximum availability. |
