MODEL
|
PB1105L10
|
PB1105L16
|
PB1105B16
|
PB1106L16
|
PB1106B16
|
PB1108L16
|
PB1110L16
|
PB1115L16
|
| Capacity (kVA) |
05 |
06 |
08 |
10 |
15 |
|
INPUT
|
| Voltage Range |
160V~280V AC, Single Phase (3 Wire, L+N+PE)
|
| Frequency Range (Hz) |
50Hz ±10%
|
|
OUTPUT
|
| Power Factor |
0.8 (Standard), 0.9 (Optional)
|
| Voltage (V) |
220V / 230V / 240V ±1% (L+N+PE)
|
| Frequency (Hz) |
50Hz ±0.1%
|
| Waveform |
Pure Sine Wave
|
| THDv |
≤1%
|
| Efficiency |
93.0%
|
| Overload |
110-125% for 10 Min, 125-150% for 60 Sec, >150% for 1 Sec.
|
| Isolation Transformer |
Inbuilt Isolation Transformer
|
|
BATTERY
|
| Battery Voltage |
120V DC |
192V DC (168V and 180V DC Optional)
|
| Charging Current (Max) |
1A ~ 10A Standard (High Rating Optional)
|
| Charging Time |
4-5 Hrs. to 95%
|
|
SYSTEM FEATURES
|
|
Display
|
LCD |
Input and Output Voltage, Input and Output Frequency, Load & Battery %
|
| LED |
Mains, AC Mode, DC Mode, Low Battery and Overload
|
| Alarm |
Battery Low Voltage, Abnormal Power Supply, UPS Failure, Overload
|
| Protection |
Battery Low Voltage, Overload, Short Circuit and Over/Voltage
|
|
ENVIRONMENT
|
| Temperature |
Operating: 0~50°C*, Storage: -15°C ~ 60°C
|
| Humidity / Altitude |
0~95% RH Non-condensing / <1500 M
|
| Noise |
≤45dBA
|
≤50dBA
|
|
STANDARD
|
| Quality |
ISO 9001, ISO 14001, ISO 27001, ISO 45001, ISO 50001, BIS, RoHS
|
| Safety |
IEC/EN62040-1
|
| EMC / Protection |
IEC/EN62040-2, IEC/EN62040-3, Complying to CE
|
|
PHYSICAL
|
|
Dimension WxDxH (mm)
|
250x550x500
|
250x550x680
|
250x550x500
|
250x550x680
|
280x615x685
|
350x650x785
|
| Weight (Kg) |
54 |
51 |
98 |
52 |
99 |
73 |
76 |
104 |
|
COMMUNICATION INTERFACE
|
| Optional |
SNMP / ModBus / Dry Contact / USB / RS-485 / RS-232
|
| Monitoring Software |
NetAgent Utility v5.8 / View Power / UPSilon 2000 / Muser 4000
|
